BASEMENT TANKING  & WATERPROOFING MEMBRANES

OLDROYD CAVITY DRAINAGE MEMBRANES

The Oldroyd range of Cavity Drainage Membranes can be used for a wide range of waterproofing an civil engineering applications including:  Interior Walls Brochure

• Damp-proofing (walls)
• Damp-proofing (Floors)
• Waterproofing Concrete Slabs
• Preventing Rain Penetration
• Basement Waterproofing (Newbuild)
• Basement Waterproofing (Refurbishment)
• Barn Conversions
• Radon & Ground Gas Mitigation

Oldroyd XV Clear   For Floors & Walls

Oldroyd Xv Clear is a semi-transparent, studded cavity drainage membrane manufactured from polypropylene. It is specifically designed for application to damp / contaminated internal floors and walls, and is particularly useful in basement waterproofing / conversion applications. Oldroyd XV Clear - Data Sheet .

Oldroyd Xv Clear is applied to walls and ceilings by means of special sealed fixing plugs (Oldroyd Brick Plugs), while on floors, there is normally no need for any form of fixing. The semi-transparant nature of Oldroyd Xv Clear makes it easy to locate suitable fixing points (e.g. avoiding soft mortar beds).

On walls, Oldroyd Xv Clear can be covered with plasterboard using timber battens or the Fastframe Drylining System. On floors a screed or a floating timber floor can be applied on top of Oldroyd Xv Clear. When used as a basement waterproofing system, Oldroyd Xv Clear should be used in conjunction with the Aquadrain perimeter drainage system and the Safeguard Sentry Sump System

Oldroyd Overseal Tape  For membrane joints & overlaps - 20 metre rolls

Oldroyd Overseal Tapes are used for sealing over joints between Oldroyd cavity drain membranes and other materials. They can also be used for sealing around services and "difficult" details. Typically the 75mm width Overseal tape is used for sealing butt joints and overlaps. The 200mm-width Overseal Tape is generally used for sealing flange joints on the floor.

Oldroyd Double Sided Sealing Tape

Double sided tape for sealing between sections of Oldroyd cavity drainage membranes.

Oldroyd Brick Plugs    For attaching membrane to walls   ( Yellow )

Fixing unit to secure Oldroyd Xv cavity drainage membrane to walls - available with and without seals. The hole in the head of the plug accepts a No.12 screw. This allows timber battens or an aluminium framing system to be secured to the membrane - providing a means for plasterboard to be applied. Oldroyd Brick Plugs expand slightly when a screw is inserted - allowing a tight fix to be achieved even on difficult .

Oldroyd XP Plaster Membrane    ORDER LINE 0800 047 6775

Oldroyd Xp Plaster Membrane (formally Oldroyd P) is a studded polypropylene waterproofing membrane with a special mesh welded to one side. It is fixed to damp, contaminated walls using Oldroyd Plaster Plugs, with the studs facing the wall. This creates an air-gap which allows the wall to breathe whilst blocking the passage of moisture. On the reverse side of the membrane, the special mesh can be plastered onto, allowing a dry plaster finish to be achieved without the risk of contamination from any damp or salts in the wall.

Typical areas of application include Covering damp & contaminated walls , Basement conversion projects , Barn conversion projects , Protection against penetrating damp.

Oldroyd Xp can be used above or below ground, however, we recommend that our technical department is consulted before using the product below ground. Oldroyd Xp Plaster Membrane is especially useful in situations where a damp wall is contaminated by salts or the residue of previous attempts to waterproof the wall (such as bitumen). Unlike cementitious, epoxy, or bitumen coatings, Oldroyd Xp can be applied directly to contaminated surfaces with minimal preparation. Oldroyd XP Plaster Membrane Data Sheet .

Oldroyd Plaster Plugs   For fixing Plaster membrane to walls   ( Blue )

Fixing unit to secure Oldroyd Xp plaster membrane to walls - available with and without seals.When purchasing Plaster Plugs without seals, please remember to purchase Oldroyd Sealing Rope to provide a seal. Alternatively, our Plaster Plugs WITH seals offer considerable time-savings when compared with buying our standard Oldroyd Plaster Plugs and using Oldroyd Sealing Rope to provide a seal.

Oldroyd XV20 Flooring Membrane   For Internal basements

Oldroyd Xv20 is a large (20mm) stud-size cavity drainage membrane with applications in waterproofing, drainage, and ground-gas control . Oldroyd XV 20 Data Sheet .

Oldroyd Xv20 benefits from large 20mm dimension studs providing greater drainage and flow capacity than standard cavity drain membranes. For this reason Oldroyd Xv20 is ideally suited to civil-engineering applications and the waterproofing of large commercial basements. Typical applications include: Internal basement waterproofing , Waterproofing of contiguous piling / diaphagm walls  , Tunnel waterproofing , Radon and ground gas protection , Land slip stabilisation .

Aquadrain Perimeter Drainage Channel

Aquadrain is perimeter drainage channel designed to provide additional protection at the vulnerable wall-floor junction in basement waterproofing applications. Aquadrain is usually used in conjunction with cavity drainage membrane systems such as Oldroyd Xv Clear and  Oldroyd Xp.  Aquadrain Perimeter Chanel Data Sheet .

Sentry Sump System       Sump Data Sheet & Brochure

The Sentry Sump System has been designed to complement the Oldroyd Xv Clear studded membrane system and the Aquadrain perimeter drainage system when they are used to waterproof basements and underground structures. It was developed by Safeguard in conjunction with pumping solutions specialists, Edincare.

TRITON CAVITY MEMBRANES FOR WALLS & FLOORS

Platon waterproofing membranes and accessories are now available from Specialist Construction Supplies . With four ranges of waterproofing membranes in stock we have the largest selection of competitively priced waterproof membranes and accessories in the North of England available for quick delivery nationwide.  Tanking a cellar Guide .

Platon waterproofing membranes can be used for a wide variety of applications to include: Barn conversions , Existing basement waterproofing , Cellar conversions , Structural waterproofing , Retrofit , New Build , Damp proof membranes , Gas barriers .

Platon  P8 Cavity Membrane  For walls & Floors

Platon P8 is a tough and economical membrane for both remedial and new build construction. It is suitable for sub-ground tanking and also for use above ground to isolate walls which are damp or contaminated with salts. Platon P8 can be dry lined on walls and screeded or a floating dry board system fitted on floors .  Platon P8 Data Sheet .

Platon Plaster Base Membrane  For use with Renders & Plasters

Platon Plaster Base can be installed on internal walls and vaulted ceilings above or below ground level. The substrate remains visible through the clear membrane for precise fixing. It is suitable for use with sand and cement renders and most lightweight and renovating plasters.

Platon Plaster Base Data Sheet

Platon P20 Flooring Membrane  For Basement Floors

Platon P20 is a high capacity drainage membrane recommended for use on all floor applications below ground, due to its ability to control free flowing water. The deep stud profile is designed to resist blockages caused by lime deposits. Platon P20 Flooring Membrane .

Platon P5 Cavity Membrane  For Walls & Floors

Platon P5 is a tough and economical membrane for both remedial and new build construction. It is suitable for sub-ground tanking and also for use above ground to isolate walls which are damp or contaminated with salts. Platon P5 can be dry lined on walls and screeded or a floating dry board system fitted on floors.  Platon P5 Data Sheet .

Platon Brick Plugs & Seals   For Fixing Platon Membranes to walls

Platon Brick Plugs are used to secure Platon System membranes to building substrates and to fix battens or tracking systems. Before using Platon Brick Plugs either wrap a bead of Platon Rope around the back of the head of the plug to form a compression seal or put a Platon Brick Plug Seal onto the plug to again form a compression seal when the plugs are fixed.

Platon Brick Plug Data Sheet .

Platon Double Sided Sealing Tape  For Membrane Joints

Platon Tape is a blue butyl tape which is used for joining Platon membranes along the flange where any of these membranes overlap. It is used for abutting joints, for repairs or where membranes have been cut to enable them to overlap, for example at corners, reveals, wall/floor joints or protrusions through the membrane. Platon Tape data Sheet .

Platon Corner Strip & Overtape  For Membrane Corners & Joints

Platon Corner Strip is a black PVC backed one-sided tape which is used for connecting and sealing all the Platon membranes together where they join or overlap. It is used for abutting joints, for repairs or where membranes have been cut to enable them to overlap, for example at corners, reveals, wall/floor joints or protrusions through the membrane. It should be regarded as an excellent general purpose sealing and repair product. Platon Corner Strip Data Sheet

VISQUEEN CAVITY DRAIN SYSTEM

Visqueen V20 Floor Membrane   Installation Guide

Visqueen V20 is used as a floor membrane as part of the Visqueen Cavity Drain System. The membrane can be used in vertical (wall) applications where a higher drainage capacity is required or complex convoluted wall shapes . The system is typically used for internally tanking basements within new, existing and retrofit build projects. The system can also be used for heritage buildings and in conservations projects.Visqueen V20 data Sheet .

Visqueen V8 Wall Membrane

Visqueen V8  is used as a wall membrane and part of the Visqueen Cavity Drain System. The system is typically used for internally tanking basements, sub structures and retaining walls within new, existing and retrofit build projects. The system can also be used for heritage buildings and in conservations projects. Visqueen V8 Wall Membrane Data Sheet.

The membrane is tough but pliable and can be bent round corners and projections without risk of breaking, even in very low temperatures. The product can be easily cut with a knife or scissors. The membrane is an integral part of Visqueen’s Cavity Drain System which effectively acts as a below (and some above) ground water management system.

V20 Sealing Rope / V8 D/S Sealing Tape

Visqueen V20 Sealing Rope is a high performance double-sided butyl rubber tape with excellent adhesion and  exibility properties. The sealing rope is primarily used to bond Visqueen V20 Floor Membranes to ensure a watertight seal. It is used around service pipes and is also applied around the rim of Visqueen Masonry Plugs forming a sealing gasket between the plug and membrane. Visqueen V8 Double Sided Sealing Tape is double sided butyl rubber tape with excellent adhesion properties and  exibility properties. The sealing tape bonds together Visqueen V8 Wall membrane to ensure a watertight seal.

CD Cornerstrip  /  Masonary Plugs   Visqueen Accessory Data Sheet

Visqueen CD Corner Strip is a single sided butyl rubber self adhesive tape. The tape is primarily used to seal the 90 degree Floor/Wall junction and sealing around service entry seals such as pipes, ductings or steel stanchions. Visqueen Masonry Plugs are made from Polyoxymethylene and are 10mm diameter and 75mm in length. The plug is used in conjunction with Visqueen Sealing Rope around the rim of the plug to effectively form a sealing gasket between the plug and vertically  xed membrane. It is intended for use into soft brick or stone.

Visqueen Water Channel Accessories

The Visqueen cavity drainage systems must be maintainable and water channel is used to facilitate this . The following are available as part of the system , water channel, water channel outlet, water channel end outlet, water channel rodding eye unit, water channel corner rodding eye , water channel connector, water channel T Piece , water pump pro and water pump pro plus . Call for price on 0800 0476775 . Visqueen Accessory Data Sheet .

RIW Cavity Drain  Cavity drain R20 Data Sheet        Cavity Drain R7 Data Sheet

RIW Cavity Drain R20 & R7 Cavity Drain

Cavity Drain R20 is used in situations where site conditions or structural design make it difficult or impossible to use traditional tanking methods. Cavity Drain R20 is used to collect water entering the structure and channel it to a sump or collection point for disposal (see details). When designing Type C (drained) protection, as classified in BS 8102: 2009, the product applied correctly, is capable of providing the levels of protection required for Grade 1, 2 & 3 basements.

Cavity Drain R7 is used in situations where site conditions or structural design make it difficult or impossible to use traditional tanking methods. Cavity Drain R7 is used to collect water entering the structure and channel it to a sump or collection point for disposal (see details). Cavity Drain R7 is suitable for use on floors and ceilings, please consult RIW for further information/ guidance.

When designing Type C structures (drained) protection, as classified in BS 8102: 2009, the product applied correctly, is capable of providing the levels of protection required for Grade 1, 2 & 3 basements .  RIW Cavity Drain Ancillaries Data Sheet .

SIKA CAVITY DRAINAGE SYSTEM  Installation Guide

Sika Cavity Drainage Membranes

Sika® Standard Drainage Membrane - a 5 mm polypropylene cavity drain membrane suitable for dry lining. Sika® HD 20 Membrane – a high-density polyethylene, high capacity cavity drainage membrane,  used for floors. Sika® Plaster Drainage Membrane – a 5 mm high-density polyethylene cavity drain membrane suitable for over plastering.  Sika Cavity Drainage Brochure

Sika® Cavity Drainage membranes can be used where site conditions or the design of the structure make it difficult to use Sika® 1 Pre-Bagged Waterproofing System or other traditional tanking methods. Sika® Internal Cavity Drainage membranes work on the principal of allowing water to penetrate the structure, collect it and manage it into a suitable drainage system for disposal. The membrane are fixed to the walls using special plugs with minimum surface preparation required to the substrate. Once the membrane is has been fitted, wall surfaces can be dry lined or plastered and the floors can be screeded.

NEWTON WATERPROOFING SYSTEM 500

Newton Waterproofing Systems provide complete structural waterproofing and damp proofing solutions for new and existing buildings

Newton System 500 is a Maintainable basement waterproofing solution ideal for new-build basements and refurbishment projects. It is a maintainable system – so complies with the British Standard for Waterproofing BS8102.

Newton 503  Cavity Drain Membrane   For Walls & Floors

Newton 503 3mm cavity drainage membrane for basements is a high quality cavity drain waterproofing membrane suitable for use internally below the ground to retaining walls, vaulted soffits and floors and is  BBA approved. As a waterproofing membrane as part of Newton System 500 it can be used as both the wall and the floor membrane for the waterproofing of: Basements , Cellars , Vaults , Tunnels and Arches. Newton 503 Data Sheet

Newton 503 Mesh Cavity Drain Membrane

Newton 503 Mesh is a 3mm Meshed Cavity Drain Membrane for Below Ground – the meshed surface provides an excellent ’key’ for lime mortars, renders, plasters or dabbed plasterboard. BBA Certified . It is suitable for new build and existing basements  Newton 503 Mesh Data Sheet

Newton 503 Mesh is guaranteed against deterioration for 30 years, and has a life expectancy of at least 50 years (DIN 9001:2000). It is inert with high compressive loading stability , It is highly resistant to water, alkalies, saline solutions and organic acids, and it is not effected by minerals. It is also resistant to bacteria, fungi and other small organisms.

Newton 508 Cavity Drain Membrane    For Walls & Floors

Newton 508 is the most commonly used membrane within the Newton System 500  waterproofing system. Suitable for use internally below the ground to retaining walls, vaulted soffits and floors. Does not require extensive and damaging preparation to the wall Surface. Speed of installation. Provides vapour control and when used with humidity control systems is capable of delivering an environment to all levels within a Grade 3 environment to BS8102:2009 , Independently certified as a barrier to hydro-carbon gasses, radon and methane.

Newton 508 Mesh Cavity Drain membrane

8mm Meshed Cavity Drain Membrane for Basement Walls, Floors and Vaulted Soffits

Suitable for retaining walls and vaulted soffits. Meshed surface provides an excellent ‘key’ for renders, plasters and plasterboard. Newton 508 Mesh is typically used where space prevents the use of a dry-lining frame or block wall as the wall finish or where a direct rendered or plastered finish is preferred to vaulted ceilings. Its high quality meshed surface provides an excellent ' key' for lime mortars, renders,plasters or dabbed plasterboard .

Newton 520 Membrane Basement Floors

With its 20mm deep stud profile, Newton 520 is used within Newton System 500 as a high drainage capacity floor membrane where it is anticipated that there may be a risk of severe water penetration. BBA certified.  Newton 520 Data Sheet

Newton Basedrain  Perimeter Basement Drainage

Newton Basedrain is the drainage system used most commonly within the Newton System 500 waterproofing system. It compromises a range of products that collectively receive water ingressing at weaknesses within the structure and then discharge the collected water to a Newton Sump System or safe drainage .The drainage system compromises a range of products that collectively receive water ingressing at weaknesses within the structure and then discharge the collected water to a Newton Sump System or safe drainage (drainage that is below the level of the basement floor that cannot back-up or block)

Basedrain - Drainage conduit for the perimeter of the area to be waterproofed. Is situated at the base of the wall membrane . Floordrain - Drainage Conduit for collection of water at construction joint to the floor and to replace Basedrain at door thresholds. Floordrain is also used to connect the perimeter Basedrain to the sump. Basedrain Corner – Formed 90 degree corner. Basedrain T Piece – Formed T for a 90 degree connection to Floordrain from Basedrain and for draining through engineering brick as an alternative to open perpendicular joints. Jetting & Access Point - for inspection and maintenance access to the drainage system.
